Scintillator type:LaBr3(Ce)
Scintillator size:Φ25×25mm
SiPM Array：16-element ONSEMI J60035 SiPM array
Energy resolution(137Cs)：≤3.5%
Output Signal Polarity：+5V
Operating voltage：Positive
Operating Temperature：-40~+55
The ELBC-D25H25SIPM01 is a high-performance, standard spectrometer detector that pioneers the integration of a 1-inch Lanthanum Bromide (LaBr₃:Ce) scintillation crystal with advanced Silicon Photomultiplier (SiPM) technology. At its core is an array-based photodetection architecture comprising sixteen ON Semiconductor J60035 SiPMs, seamlessly coupled with an optimized signal summing and low-noise preamplification circuit.
This innovative design enables highly efficient gamma-ray collection and ultrafast signal processing, delivering exceptional energy resolution and high count-rate capability. Thanks to its highly integrated architecture, the detector achieves a compact form factor without compromising performance, while ensuring long-term operational stability.
Combining outstanding spectroscopic performance, space-saving design, and excellent cost-effectiveness, the ELBC-D25H25SIPM01 has become a trusted front-end detection solution for a broad spectrum of radiation measurement applications—from nuclear security and environmental monitoring to medical imaging and industrial analysis.
